LMI C9 Pump, LiquiPro Head, 93.2 GPD, 102 PSI, C921-469SI, Fluoride
Description
LMI's Series C9 Chemical Feed Pumps feature a LED display, accept multiple input controls including 4-20mA and pulse signals. Remote on/off and low-level shutoff inputs. 4-key programmable and manual control of pump speed, adjust speed from 1 stroke/hour to 100 strokes/minute. Features two pulse modes, pulse divide and pulse multiply, let you program the pump to stroke for every incoming pulse signal. Pump has remote on/off and low-level shutoff inputs. FastPrime™ Liquid Ends. Pump configured to be used with Fluoride and Hydrofluosilicic acid.
Features
- 4-20mA signal response is scalable, you can program to respond to the signal directly or inversly
- Highly accurate / consistent dosing performance
- Advanced control options
- External pacing for flow proportional applications
Includes
4-function valve, foot valve/strainer and 16 FT of polyethylene tubing
Product Specifications
Wetted Material | Acrylic Head, PVC fittings, PTFE check balls, Liquifram™ Fluorofilm™, PVDF/Polyprel® Check Valve |
Brand | LMI |
Certifications
- NSF/ANSI 61 Certified,NSF 372 Certified
