Hach Hach Online Process ORP Sensor, General Purpose Digital ORP Sensor, DRD1P5

$1,654.00 | EA
Product #: 703371
Mfr. Part #: DRD1P5

This item is in stock

Description

General Purpose Online Process ORP Sensor with Integrated Digital Electronics for "Plug and Play" with Hach sc Digital Controllers - Platinum ORP Electrode, PEEK Housing, Convertible Mount, 10m Cable

Features

  • This field-proven technique uses three electrodes instead of the two normally used in conventional ORP sensors. Process and reference electrodes measure the ORP differentially with respect to a third ground electrode. The end result is unsurpassed measurement accuracy, reduced reference junction potential, and elimination of sensor ground loops. These sensors provide greater reliability, resulting in less downtime and maintenance.

  • The double junction salt bridge creates a barrier to contamination which minimizes the dilution of the internal standard cell solution. The result is lower maintenance needs and a longer time period between calibrations.

  • The unique, replaceable salt bridge holds an extraordinary volume of buffer to extend the working life of the sensor by protecting the reference electrode from harsh process conditions. The salt bridge simply threads onto the end of the sensor if replacement is needed.

  • Encapsulated construction protects the sensor’s built-in preamp from moisture and humidity, ensuring reliable sensor operation. The preamp in the pHD analog sensor produces a strong signal, enabling the sensor to be located up to 1000 m (3280 ft.) from the analyzer.

  • The former GLI, now a Hach Company brand, invented the Differential Electrode Technique for pH measurement in 1970. The pHD™ sensor series (U.S. Patent Number 6395158B1, dated May 28, 2002) takes this field-proven technology to a new level.

Includes

Sensor with 33 ft cable and manual
